6 Digital preset Scale C3E-R-220 AC 110-240V Maximum Speed 10K. Input and Control Signals can be Set to NPN or PNP Mode, Input Signals: Input, Pause, Reset;Use Long-Life relays;

FeaturesDIN(48X48mm) digital display counterRange 1-999999withUP/DOWN mode Max.10kpcsPreset scale range: 0.001-99.999, preset scale counting functionMCU High Precision and Reliable EEPROM Storage for Digital Control10-year data NPN and PNP input can be switched9.2mm height LED, anti-glare, clear and visible displayTactswitch for up or down set value easily operate KeylockFunction prevents misoperation of switching power supply and Low consumptionSpecificationsPower supply and input: power supply and input circuit isolationVoltage (order): AC100-240V+10%50/60Hzs5VAAC/DC 12-24V+10%<4VACharacter: PV: 6 digits 9.2mm high bright red LED SV: 6pcs 7.0mm high bright green LEDContact output (C3E-R): AC250V3A (resistive load) NO/NCSSR output (C3E-V): DC12V (Max.40mA) Life Expectancy: Mechanical: 10,000,000 operations minimum. Electrical: 100.000 operations minimum. Maximum counting speed 10kpcs(Rate 1:1)100Hz.5KHz10KHz Default scale range: 0.001-99.999Data backup: 10 years, can be set whether to saveControl signal: ≥5ms (Reset, Gate)Control/Input Type Contact/No-voltageinput(NPNVoltageinput(PNP)Inputlevel: High(logic)4.5to 30VDCLow logic) 0to2.0VDCExternal power supply: DC 12V/50mA(Max.) for sensors onlyStart sequence: ≥100msReset method: power on/external/manualCut size: 45X45mmInstallation method: flush installation and screw terminalWeight: About 120gAmbient temperature: Working: -10~55°C (no icing or condensation)Storage: -25~65℃ (no condensation)Ambient humidity: 35~85%RH

• The high accuracy and reliability of the counter, combined with its ability to store data for up to 10 years, make it ideal for use in applications where precise and reliable counting is critical.
• The preset scale range and count function make it easy to customize the counter to meet the specific needs of different applications, allowing users to quickly and easily adjust the counter to suit their needs.
• The key lock function prevents mistaken operation, reducing the risk of errors and increasing productivity and efficiency.
• The low power consumption of the counter makes it an energy-efficient choice for applications where energy consumption is a concern, helping to reduce overall energy costs.
• The versatile input switching options (NPN and PNP) and contact/non-voltage input types make it easy to integrate the counter into a wide range of applications, allowing users to choose the input type that best suits their needs.
