5 Pcs 24G MmWave HLK-LD2410C Human Presence Radar Sensor Intelligent Sensor Motion Detection Module

ALOEU LD2410C human body sensing module adopts 24GHz millimeter wave radar sensor technology. Compared with other solutions, it has obvious advantages in human body sensing applications:1.In addition to being sensitive to moving human bodies, it can also sensitively sense static, micro-moving, sitting and lying human bodies that cannot be identified by traditional solutions;2.It has good environmental adaptability, and the sensing effect is not affected by the surrounding environment such as temperature, brightness, humidity and light fluctuations;3.It has good shell penetration and can be hidden in the shell to work without opening holes on the of the product, which improves the aesthetics of the product;4.It can flexibly configure the farthest sensing distance and the sensitivity on each distance door to achieve flexible and fine personalized configuration.The LD2410C human body sensing module can detect and identify the human body in motion, fretting, standing, sitting and lying down. It supports multi-level parameter adjustment and can be widely used in various scenarios of AIoT. The common types are as follows1.Human body sensor light control2.Human body induction of advertising screen and other equipment3.Life safety protection4.Smart 5.Intelligent securityColour:BlueMaterial:PC+metalPackage Contents:5 * Sensor ModuleOnly the above package content, other products are not included.Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.

• 4.Small and simplified, the minimum size is only 16*22mm.Supports various installation methods such as ceiling hanging and wall hanging
• 1.Plug and play, easy assembly.The sensing distance is up to 6 meters
• 3.Multi-level intelligent parameter adjustment can be realized through Bluetooth or serial port to meet the needs of scene changes Visual debugging and configuration tools
• 2. detection angle, coverage up to ±60 degrees.Accurate identification within the interval, support the division of the sensing range, and shield the interference outside the interval
